Triumph Daytona 955i 2002 - 2006
	Triumph Sprint ST 955i 2002-2004 TRIUMPH DAYTONA 955I 955    2002 - 2006  TRIUMPH SPEED TRIPLE 955   2002 - 2004  TRIUMPH SPRINT ST 955          2002 - 2004  TRIUMPH SPRINT RS 955         2002 - 2003



Sprint stock stacks in background

Factory Pro stacks installed into Daytona / Sprint airbox

Have a "properly tuned" 955i? Still won't take full throttle at low rpm? Still sounds like it's gargling with socks in the airbox? Esp. in  2nd gear, "in-town" operation?

We richened and leaned the fuel , advanced and retarded the ignition timing and never totally fixed the low rpm "business" on the, otherwise stellar, SAGEM FI equipped Triumphs.
(I think that the Cannondale / Sagem fiasco hurt Sagem in the mc industry........)

This mod allowed us to finally make the bike run smoothly at cruise rpm / small throttle opening.

Incidentally, the Sagem fuel injection worked fine - IF properly tuned. Tuning the FI with Tuneboy is the only way to get things "BEST. A power commander will make it better, but not as well as properly tuned with Tuneboy.

And if it's a power commander custom "tuned to an af ratio....... and not to "best power", you're missing a lot........

The dealer's Triumph tunes were maybe OK for the bike that they were made on, but, as we all know (or will know), each bike is an individual and one can't expect a "blanket" tune to make all bikes run perfectly (even with the same accessories installed). It's probable that manufacturers have to do emissions testing on each "tune" to allow the dealer to change the "tune", but it's only by chance that a bike will be perfect with a dealer downloaded "tune" (but it does give online owners groups a lot to talk about).....

Anyhow, this is how I installed some of our Superflare stacks on a 955 and was able to use Tuneboy to make it run nice at low rpm and stop that annoying "gargling" at cruise in town.

I don't expect that everybody will be annoyed by the "gargling" and full throttle / low rpm bogginess - it's something that annoys the heck out of us that it annoys -

You need to buy a set of:
3     V45.3 stacks in 60mm length
3     S64 adapter rubbers (patented)
Figure $172.50 for the parts + shipping
(add $20 for us to modify the stack - but we won't do the rubber)

pn: VEL-TD95-60x3

800 869-0497


These will have to be purchased direct from Factory Pro / 415 491-5920 9-6 pac time, M-F.

You'll need to modify the #3 stack to let it clear the inside of the airbox. It's a simple mill operation or you could use a disk sander. The #3 rubber will have to be hand trimmed to clear the inside of the airbox, also. Since I was at the tuning building, and not the machine shop, you'll see that I hit the belt sander.......... The 2.235" / 56.8mm stack width is a good number and if you are off a mm or so, it's fine.

If I could figure out a way to mod the rubber nicely, I'd sell a set of pre-made stacks. I can't figure out how do it to cost effectively, so if you want to fix the running, you'll have to do the rubber mod and maybe the stack mod (unless you pay us extra) it or the person doing the installation will have to do the stack and rubber mods. On the rubber mod, it's just the part that in on the inside of the airbox. Test fit the rubber and you'll see.

Needless to say....... there are no guarantees, no warranties, no implied warranties, no unimplied warranties, no warranties of fitness for any purpose, no fitment warranties or any responsibility for what you do in your spare time, your wife, your kids, the dog, your neighbors, your boss, your in-laws, your truck, etc. All taxes and duties are the responsibility of the user and so on.......... I'm not forcing you to buy this stuff that doesn't fit a triumph... yadda... yadda.... yadda...... (yes, evil curmudgeon, Marc Salvisberg wrote this....)

Have fun!

comments and additions? Click here to email

Grant Kei's 2004 955i

alloy stack / adapter rubber concept patented
Top view of stack	Bottom view of stack
	Upper edge (the part that's inside the airbox) trim

		These are the Sprint stock stacks. Ours are a bit shorter. The stock rubber Daytona stacks are a bit shorter than our billet 60mm stacks. I think that the stock Sprint rubber stacks are a bit too long and the shorter stock Daytona rubber stacks are a bit too short...........
